Product Overview
As electrical safety regulations (such as BS 7671) evolve, the demand for individual circuit protection using RCBOs has surged. However, installing standard RCBOs into older, single-busbar consumer units often results in a tangled, unmanageable mess of wires. The CHNAILE Space-Saving Flying Lead RCBO elegantly bypasses this issue. Occupying only a single 18mm DIN-rail module, it features a pre-attached, highly flexible blue neutral wire (pigtail). This allows electricians to route the neutral directly to the panel's common earth/neutral bar effortlessly. Combined with a robust 16A continuous capacity, 6000A short-circuit defense, and precise 30mA life-safety leakage detection, it is the ultimate contractor-friendly safety upgrade for constrained electrical enclosures.
Technical Parameters
Device Category: | AC RCBO (Residual Current Circuit Breaker with Overcurrent Protection) |
|---|---|
Wiring Architecture: | Solid Neutral with Blue Flying Lead (Pigtail) |
Form Factor: | 1-Module Width (Ultra-Slim 18mm) |
Rated Current (In): | 16A (The international standard for caravan/marine shore power) |
Rated Operating Voltage (Ue): | AC 230/240V~ |
Earth Leakage Sensitivity (I∆n): | 30mA (Strict human electrocution defense) |
Short-Circuit Breaking Capacity (Icu): | 6000A (6kA) |
Residual Making/Breaking Capacity (IΔm): | 6kA (Extreme mechanical endurance) |
Visual Identifier: | Blue Operational Toggle with Orange 'T' Test Button |
Standard Compliance: | IEC/EN 61009-1 (Compatible with UK/AU specific board designs) |
1. Contractor-Optimized Wiring & Safety
Effortless Pigtail Integration: Time is money for electrical contractors. The pre-crimped, highly flexible blue flying lead eliminates the need to cut and strip a separate neutral wire to bridge the breaker to the panel’s neutral bar. This vastly speeds up installation times when populating a crowded 12-way consumer unit.
1-Module Space Optimization: By shrinking the complex magnetic trip coil and residual current toroid into a solitary 18mm width, this device allows older distribution boards to be fully upgraded to individual RCBO protection without the exorbitant cost of tearing out the wall to install a larger enclosure.
Instant 30mA Shock Prevention: Designed to monitor the phase-to-neutral vector sum meticulously. Should a minuscule 30mA of current escape due to degraded wiring or human contact with a live chassis, the breaker violently severs the 16A power feed in under 0.1 seconds, averting fatal tragedies.
2. Ruggedized Engineering for Demanding Locales
High-Fault Endurance (IΔm=6kA): Packing a 6000A residual making capacity into an 18mm shell ensures that if the breaker is manually closed onto a severe, pre-existing earth fault (such as a flooded outdoor socket), the internal mechanism will safely absorb the 6kA blast without shattering.
V0-Rated Thermal Armor: Upgrading older boards often means less ventilation. The housing is molded from a premium fire-retardant thermosetting polymer that efficiently manages internal heat dissipation, ensuring the 16A thermal-magnetic calibration remains perfectly accurate over decades of use.
3. Target Application Scenarios
Because of its unique flying lead architecture and strict 16A/30mA safety rating, this RCBO is exclusively sourced by global EPCs and wholesalers for:
UK & Australian Consumer Unit Retrofits: The absolute go-to component for electricians upgrading residential distribution boards to comply with the latest individual-circuit RCBO mandates (e.g., BS 7671 Amendment 2).
Caravan Park Power Pedestals: Serving as the mandatory 16A outdoor hookup isolator, providing dedicated, space-saving life protection for individual visiting motorhomes and RVs.
Marina Shore Power Hookups: Delivering essential earth-leakage defense for damp maritime environments where space inside the dockside stainless-steel bollards is extremely limited.
Temporary Event & Construction Boards: Acting as the fast-wiring, rugged main disconnect for temporary 16A power outlets supplying outdoor lighting and power tools.
4. Global B2B Partnership with CHNAILE Factory
Factory-Direct Retrofit Solutions: Bypassing international electrical wholesalers allows us to offer you aggressive factory-direct pricing on these highly sought-after pigtail RCBOs, significantly optimizing your regional distribution margins.
Rigorous Micro-Current Calibration: We guarantee life-saving precision. Every single flying-lead unit undergoes exhaustive automated testing to verify the exact 30mA/0.1s tripping threshold and 6kA short-circuit suppression prior to international export.
OEM Customization for Panel Builders: Leveraging our vast manufacturing footprint, we offer tailored white-labeling services, including bespoke faceplate printing and custom wire lengths for the blue flying lead to perfectly match your proprietary distribution board designs.
